| Engine Specifications | |
|---|---|
| Engine Brand | PERKINS |
| Engine Model | 1104A-44TG1 |
| Standby Power (Kw/hp) | 65,6/87,9 |
| Engine Speed (r.p.m) | 1500 |
| Total Displacement (L) | 4,4 |
| Cylinder Arrangement | 4-L |
| Bore x Stroke (mm x mm) | 105 x 127 |
| Compretion Ratio | 17,25:1 |
| Governor Type | Mechanical |
| Aspiration System | Turbocharged |
| Injection | Direct |
| Cooling System | Water Cooled |
| Electrical System (VDC) | 12 |
| Oil Capacity (L) | 8 |
| Coolant Capacity (L) | 13 |
| Fuel Tank Capacity (L) | 180 |
| Maximum Exhaust Gas Temperature (°C) | 550 |
| Maximum Exhaust Gas Flow (m3/h) | 684 |
| Maximum Back Pressure (kPa) | 10 |
| Cooling Air Flow (m3/min) | 89 |
| Fuel Consumption at 50 % (L/h) | 8 |
| Fuel Consumption at 75 % (L/h) | 11,2 |
| Fuel Consumption at 100 % (L/h) | 14,8 |
| Cylinder Liner Type | Wet Type-Replacable |
| Air Filter Type | Dry Type-Replacable |
| Radiator | Tropical type up to 50 °C |
| Open Type Width (mm) | 1100 |
| Open Type Length (mm) | 1750 |
| Open Type Height (mm) | 1555 |
| Open Type Weight (Kg) | 940 |
| Open Type Fuel Tank Capacity (L) | 180 |
| Alternator Specifications | |
|---|---|
| Alternator Brand | Leroy Somer |
| Alternator Model | TAL044 A |
| Frequency (Hz) | 50 |
| Nominal Power (kVA) | 70 |
| Nominal Voltage (V) | 400 |
| Phase | 3 |
| Regulated By | AVR |
| Voltage Regulation | ±1% |
| Short Circuit Current | 100% In |
| Insulation | Class H |
| IP Class | IP 23 |
| Power Factor | 0.8 |
| Efficiency (%) | 90.4 |
| THD | <2% |
| Connection Type | Star connection |
| Number of Wires | 6 |
| Poles | 4 pole |
| Bearing Type | Single Bearing |
| Canopy Type Width (mm) | 1100 |
| Canopy Type Length (mm) | 2400 |
| Canopy Type Height (mm) | 1805 |
| Canopy Type Weight (Kg) | 1320 |
| Canopy Type Fuel Tank Capacity (L) | 180 |
