| Engine Specifications | |
|---|---|
| Engine Brand | PERKINS |
| Engine Model | 403J-07G |
| Standby Power (Kw/hp) | 45510 |
| Engine Speed (r.p.m) | 1500 |
| Total Displacement (L) | 0,76 |
| Cylinder Arrangement | 3-L |
| Bore x Stroke (mm x mm) | 67 x 72 |
| Compretion Ratio | 23,5:1 |
| Governor Type | Mechanical |
| Aspiration System | Natural |
| Injection | Indirect |
| Cooling System | Water Cooled |
| Electrical System (VDC) | 12 |
| Oil Capacity (L) | 3,1 |
| Coolant Capacity (L) | 2,6 |
| Fuel Tank Capacity (L) | 55 |
| Maximum Exhaust Gas Temperature (°C) | 450 |
| Maximum Exhaust Gas Flow (m3/h) | 61,2 |
| Maximum Back Pressure (kPa) | 10 |
| Cooling Air Flow (m3/min) | TBA |
| Fuel Consumption at 50 % (L/h) | 0,96 |
| Fuel Consumption at 75 % (L/h) | 1,27 |
| Fuel Consumption at 100 % (L/h) | 1,63 |
| Cylinder Liner Type | Dry Type |
| Air Filter Type | Dry Type-Replacable |
| Radiator | Tropical type up to 50 °C |
| Open Type Width (mm) | 1000 |
| Open Type Length (mm) | 1500 |
| Open Type Height (mm) | 1230 |
| Open Type Weight (Kg) | 580 |
| Open Type Fuel Tank Capacity (L) | 55 |
| Alternator Specifications | |
|---|---|
| Alternator Brand | Leroy Somer |
| Alternator Model | TAL040B |
| Frequency (Hz) | 50 |
| Nominal Power (kVA) | 10 |
| Nominal Voltage (V) | 400 |
| Phase | 3 |
| Regulated By | AVR |
| Voltage Regulation | ±1% |
| Short Circuit Current | 100% In |
| Insulation | Class H |
| IP Class | IP 23 |
| Power Factor | 0.8 |
| Efficiency (%) | 83.3 |
| THD | < 3.5 % |
| Connection Type | Star connection |
| Number of Wires | 6 |
| Poles | 4 pole |
| Bearing Type | Single Bearing |
| Canopy Type Width (mm) | 1000 |
| Canopy Type Length (mm) | 2200 |
| Canopy Type Height (mm) | 1480 |
| Canopy Type Weight (Kg) | 650 |
| Canopy Type Fuel Tank Capacity (L) | 55 |
